Warranty

•  5 year motor warranty, 2 year electronics warranty

Technical Data and Features

- 1/2 HP AC motor power
- 18m2 maximum door size
- 1.2 million transmitter code combinations
- 303MHz transmitter frequency
- "Auto Safety Reverse" function included (when the “Photo Eye” system is fitted)
- Minimum headroom of 50mm
- Optional "Photo Eye" protection
- “Overload Adjustment” included
- Courtesy light included
- Manual disengagement system
- Manual limit system
- Pole/chain drive type
- 2 handsets and wall button
- 5 year motor warranty, 2 year electronics warranty

Specification

• 1/2 HP AC motor type
• 18m2 maximum door size
• 1.2 million transmitter code combinations
• 433.92MHz transmitter frequency
• “Auto Safety Reverse” function included
• Minimum headroom of 50mm
• Optional “Photo Eye” protection
• 5 year motor warranty, 2 year electronics warranty
• Courtesy light included
• Manual disengagement system
• Manual limit system
• Pole/Chain drive type

​Electrical Rating

• Input AC 115V 60Hz / AC 230 50Hz
• Current 3.5A / 2.5A
• Power 375W
• Standby power 2W

​Motor

• Type 115V / 230V Single phase
• Max. capacity 75kg
• Huge 2yr Motor warranty

Recommended Lifting Forces

• Max. Lifting force 60kg
• Rated Lifting force 15kg
• Door travel rate 135mm/second

Door Travel

• Door travel limits 10 feet

Courtesy Light

• Light bulb E27 60W
• Lighting time 4.5 minutes / 2.5 minutes

Transmitter

• Frequency 303
• Operation range 50m (open field)
• Coding type Fixed-code
• Battery 12V (A23 Alkaline) x 1

Miscellaneous

• Operating temperature -20 C ~ +50 C

Operation Features

• Safety reverse on closing and stop on opening
• Force adjustable by digital push button
• Auto closing with Photo eye (Optional )

Accessories (Optional)

• Wall Push Button (Standard / Illuminated / Wireless)
• Wall Control Box
•  1 / 2 / 3 / 4 Button Transmitters
• Safety Photo Eye System
